What Is The 4-Stage Diagnostic Protocol?

Standardized diagnostic execution flow engineered to eliminate guesswork and replace components with mathematical certainty.

01

Static OCV Inspection

Measure resting Open-Circuit Voltage after a 12-hour surface charge dissipation. Verify 12.60V baseline at 70°F.

02

Dynamic Starter Inrush

Capture starter cranking amp draw and voltage sag. Confirm voltage stays strictly above 9.60V during starter engagement.

03

CAN Sleep & Drain Test

Allow 45-minute module sleep cycle. Measure parasitic drain using in-line milliamp shunt. Isolate draws above 50mA.

04

Factory Verified Repair

Perform precision OEM torque, clean terminal posts with brass brush, apply dielectric grease, and execute BMS reset.

Factory Tolerances & Battery Benchmark Matrix

Authoritative electrochemical specifications and operating boundaries across modern automotive chemistry types.

Flooded Lead-Acid

12.60V
  • 100% Resting Charge12.60V – 12.66V
  • 50% Discharged Floor12.20V
  • Cranking Inrush Floor> 9.60V
  • Alternator Float Voltage13.80V – 14.40V
  • Electrolyte MaintenanceCheck Acid Levels
  • Typical Service Life3 – 5 Years
View Flooded Guides →

Lithium (LiFePO4)

13.60V
  • 100% Resting Charge13.60V – 14.40V
  • 50% Discharged Floor13.10V
  • Cranking Inrush Floor> 11.00V
  • Alternator Float Voltage14.40V Constant
  • Internal ProtectionIntegrated BMS Board
  • Typical Service Life8 – 10+ Years
View Lithium Guides →
